flushglass.ie, flat rooflights, Irish windows, modern roof lights


CHEAPEST CERTIFIED DESIGN

IRISH MANUFACTURED

PATENTED NEW PRODUCT




Flushglass explained on video





WHY FLUSHGLASS?

About the product.

In designing a new flat rooflight ruhm set out to tick all the boxes possible, resulting in complete satisfaction for Architects, Home Owners and Builders.



THE ARCHITECT

✓ CERTIFIED DESIGN

✓ ATTRACTIVE FINISH


THE HOME OWNER

✓ ECONOMICAL PRICE

✓ NO FRAME VISIBLE INTERNALLY


THE BUILDER

✓ LEAK PROOF DESIGN

✓ CONVENIENT FINISH OF PLASTERBOARD AGAINST GLASS

✓ TOP OF UPSTAND BLACKED OUT BY SUPPORT FRAME

✓ FAST DELIVERY TIME FOR UNIT

✓ FAST INSTALLATION TIME ON SITE






FLUSHGLASS EXPLAINED

Video explaining the many different advantages of the new Flushglass rooflight.








WANT SOMETHING DIFFERENT?

Ruhm.

Why not visit ruhm.ie for specialist rooflights, glazed roof's, conservatories and orangeries.

For over 20 years now, ruhm has specialised in building conservatories, sunrooms and orangeries. Always working to the highest standards, the team has first calss experience proven by the volume of work undertaken throughout the country. Visit the website to see some examples.





FLUSHGLASS
TECHNICAL INFORMATION

Survey Form:

Survey Order Form Click for Survey Order Form

Drawings :

Triple Glazed Section Click T-G Section

Double Glazed Section Click D-G Section

Setting out for Insulated Board Internally Click for I-B-I

Glass :

Double Glazing specification Click for D-G specification

Treble Glazing specification Click for T-G specification

Note on Nickel sulphide (NiS) inclusion in glass Click for Note on Nickel sulphide (NiS)

Certification :

Heat Profile Double Glazed Click for Heat Profile D-G

Heat Profile Treble Glazed Click for Heat Profile T-G

Double Glazing Thermal Simulation Certificate Click for D-G Thermal Simulation Cert

Treble Glazing Thermal Simulation Certificate Click for T-G Thermal Simulation Cert

Considerations for glass specifications to use Click for Considerations

Warranty Conditions :

Terms Attached in PdF Click for PdF

For a video on how to install the Flushglass rooflight click link below.

Installation Video here



TYPICAL PRICES

All the following prices are ex VAT.
All the following prices are for supply only and excluding delivery, fitting and vat.
All dimensions refer to finished external upstand dimensions.

mm
Size Double Glazed Treble Glazed
800 x 1200 525 640
1000 x 1350 630 790
1200 x 1500 785 955
1200 x 2000 965 (72kg) 1,135 (110kg)
1200 x 2500 1080 1,310
1350 x 2500 1,155 1,425
1000 x 3000 1,095 1,345 (110kg)


For units weighing up to 110kg four men can conveniently carry the glass unit.

Above this weight it is recommended to have additional help or the hire of a crane and pneumatic suckers to raise glass from ground to flat roof area at an additional cost.

All prices are for supply only and are excluding measuring, delivery, fitting and VAT.

Measuring, delivering, fitting and vat are additional to the above figures.

Measuring Dublin area for 1-4no units is €60
OR Builder must provide a completed survey form together with a photograph of the entire completed upstand and open from the roof area.

Delivery charges and fitting are additional to the above figures.

Delivery Dublin area.

150 (for 1no)

Delivery and fitting Dublin area.

350 (1no)

475 (2no)

Measuring, delivering and fitting outside the dublin area are subject to individual quotation.





FAQ



If you cannot find the answer to your question, you can contact us directly here



Q. IS THE NEW FLUSHGLASS ROOFLIGHT CERTIFIED?

A. Yes the new Flushglass is certified. The treble glazed version has a centre pane value of 0.7 and overall unit value of 0.87



Q. WHAT TYPE OF GLASS IS SPECIFIED IN THE NEW FLUSHGLASS ROOFLIGHT?

A. The rooflights are fitted with safety toughened glass as standard. All double or treble glazed units are argon filled, have a warm edge bar incorporated and use soft coat technology on the inner layer for high performance. At additional cost a laminated bottom pane can be supplied.



Q. WHAT COLOUR DOES THE FLUSHGLASS ROOFLIGHT COME IN?

A. The flushlight comes in a standard colour of ral 7021 black grey matching most roof surfaces and is only visible to the exterior. From the interior there is no frame visible.



Q. WHAT SIZES ARE AVAILABLE IN THE FLUSHGLASS ROOFLIGHT?

A. The maximum length of rooflight is 3000mm (measured externally on the upstand) and the widths can vary from 600 to 1500.



Q. HOW NEAR A PARAPET OR HOUSE WALL CAN I FIT A FLUSHGLASS ROOFLIGHT?

A. The upstands for the rooflight can be no nearer than 250 from any vertical wall or obstruction.



Q. WHAT ARE THE PAYMENT TERMS?

A. A 50% deposit and balance on delivery or by bank transfer the day before.



Q. WHAT IS THE NORMAL DELIVERY PERIOD FOR THE FLUSHGLASS ROOFLIGHT?

A. 2-3 weeks from receipt of deposit



Q. CAN I PAY BY CREDIT CARD?

A. Yes, see details on the website.



Q. DO YOU STOCK CHEAPER STANDARD SIZES OF FLUSHGLASS?

A. No, as they are all custom designed for your particular needs





Contact Us




Please complete the form below






TOM DONNELLAN

B.E.C. Eng (structural)

Tel: 085 855 6158

Email: info@ruhm.ie



Name
Name



Celebrating over 20 years in bussiness
